Air Caster Roll Movers
Roll movers with built-in air casters for manually repositioning heavy, compact loads over short distances.
Aerofilm Systems
Air Jacks
Pneumatic jacks that raise a heavy assembly a controlled amount so air casters or transport dollies can be placed underneath — no crane required.
Models
- AJ-8
- AJ-20
- AJ-50-4
- In stock, short lead times
- Engineering support included
- Manufacturer warranty
Engineered by Aerofilm since 1972 · Exceeds ASME B30.1 2:1 overload · Used across aerospace, machine building and heavy fabrication
Products
See details
Air Jacks
Pneumatic jacks that raise a heavy assembly a controlled amount so air casters or transport dollies can be placed underneath — no crane required.
Air Planks
Low-profile beams carrying two or more air casters, for long, narrow or unevenly distributed loads.
Embedded Air Caster Systems
Air casters embedded in a platform or frame, for permanent or semi-permanent load-moving installations.
Gap Crosser
Air casters that glide over joints and cracks, for floors that are not completely sealed.
Load Module Systems
Complete load modules with air casters for moving very heavy or large loads, with centralised control.
Neoprene Air Casters
Reinforced neoprene air casters for the heaviest loads and highest pressures, from 1,100 to 175,000 lbs.
Air Caster Roll Movers
Roll movers with built-in air casters for manually repositioning heavy, compact loads over short distances.
Air Jacks
Pneumatic jacks that raise a heavy assembly a controlled amount so air casters or transport dollies can be placed underneath — no crane required.
Air Planks
Low-profile beams carrying two or more air casters, for long, narrow or unevenly distributed loads.
Embedded Air Caster Systems
Air casters embedded in a platform or frame, for permanent or semi-permanent load-moving installations.
Gap Crosser
Air casters that glide over joints and cracks, for floors that are not completely sealed.
Load Module Systems
Complete load modules with air casters for moving very heavy or large loads, with centralised control.
Neoprene Air Casters
Reinforced neoprene air casters for the heaviest loads and highest pressures, from 1,100 to 175,000 lbs.
Models
All air jacks work at 115 psi. Values are indicative — confirm the configuration for your application.
| Model | Capacity | Lift height | Collapsed height | Weight | Jacks |
|---|---|---|---|---|---|
| AJ-8 | 8,000 lbs | up to 6 in | 1.6 in | 18 lbs | 1 |
| AJ-20 | 20,000 lbs | up to 12 in | 3 in | 34 lbs | 1 |
| AJ-50-4 | 50,000 lbs | — | — | — | 4 |
Product information
Aerofilm air jacks raise a heavy assembly a controlled amount so air casters or transport dollies can be placed underneath — no crane required.
Choose the AJ-8 single bellows jack for low clearance, the AJ-20 triple bellows jack for higher lift, or the AJ-50-4 set of four jacks with a control console for synchronised lifting of large loads.
Specifications on this page are indicative and depend on load, adjustment and floor quality. Contact us to confirm the configuration for your application.
Frequently asked
Common questions before a first air caster project.
A sealed, flat and level concrete floor. Open joints, cracks and slope all increase air consumption and reduce lift. Our brochure “Air caster transport and the floor” covers the requirements in detail.
